Automatic Detection X-ray Inspection Machine for Cylindrical Battery 18650
Product Details:
| Place of Origin: | China |
| Brand Name: | Asida |
| Model Number: | XG5600 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Wooden Carton |
| Supply Ability: | 120 sets per year |
|
Detail Information |
|||
| Application: | Lithium-ion Battery | Series: | X Ray Testing Machine |
|---|---|---|---|
| Testing Capacity: | 50 Pieces Per Minute | ||
| High Light: | x ray inspection systems,battery testing machine |
||
Product Description
Online X-ray Inspection Equipment for Cylindrical Battery 18650
Brand : ASIDA
Model: XG5600
Testing products : cylindrical battery 18650
Online X-ray Inspection Equipment Usage
The equipment is mainly used in lithium electricity industry cylindrical battery online or offline automatic detection.
Technical parameters
|
X-ray Tube |
Tube Voltage |
MAX 110KV |
|
Tube Current |
MAX 450uA |
|
|
Focal Spot Size |
5μm |
|
|
Cooling Mode |
Strong wind cooling |
|
|
Image-forming System |
Flat-panel detector effective area |
54mm×48mm |
|
Resolution |
20.8lp/cm |
|
|
Camera Resolution |
2000*2249/1000*1124pixels |
|
|
Detection Precision |
Repeat accuracy |
60μm |
|
Efficiency |
Detection Efficiency |
≥50ppm |
|
False Rate |
≤2% |
|
|
Missing Rate |
0.0% |
|
|
Excellent Products Rate |
≥99.5% |
|
|
Safety Standard |
International Radiation Safety Standards |
≤1usv/hr |
Characteristic
1. Automatic sorting
Automatic detection and sorting OK/NG products.
2. Real-time monitoring.
Real-time monitoring the state of all actions, signal, hardware,and show on the software interface.
3. Images and data real-time online display
Test data and images of many parts of the same battery is shown in the same software interface, convenient observation recognition.
4. Safety protection
The whole equipment safety interlock, triple protection function, any part of the fuselage surface radiation meet safety standards.
