Computer Controlled Ionic Contamination Tester / PCB Testing Machine
Product Details:
| Place of Origin: | China |
| Brand Name: | Asida |
| Model Number: | LZ12/LZ21 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set / Sets |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Wooden Carton |
| Delivery Time: | Negotiation |
| Payment Terms: | T/T |
| Supply Ability: | Negotiation |
|
Detail Information |
|||
| Measurement Accuracy(F·S): | ±5% | Sensors Sensitivity: | 0.0001us/cm |
|---|---|---|---|
| Efficiency: | 5～15 Minutes Every Time | ||
| High Light: | pcb board testing equipment,circuit board testing equipment |
||
Product Description
Ionic Contamination Tester / Dynamic/Static Ionic Contamination Tester
Product Attributes:
|
Product name |
Dynamic/Static Ionic Contamination Tester |
|
Brand Name: |
ASIDA |
|
Model Number: |
LZ21 |
|
Place of Origin: |
China |
|
Packaging Details: |
Wooden Carton |
USAGE:
Tests for board contamination on an atomic level. This equipment can not only be used to test the electronic
components at production phase, but also to test the PCB's before and after assembly.
CHARACTERISTIC:
1. Simple computer controlled operation for: pre-heating, testing and regenerating.
2. USB and RS232 data cable compatible.
3. Real-time conductance rate and ionic chart, simplifying the testing process.
4. Advanced system security with multi-level user accounts and password protection.
5. Calefaction and temperature control, which can work at fixers temperature below 40 degrees.
6. The machine adopts negative and positive ion resin, which improves the filtering effect.
TEST PRINCIPLE :
|
Accuracy |
① Measurement accuracy(F·S):±5% |
|
Accuracy |
② Sensors Sensitivity:0.0001us/cm |
|
Efficiency |
5～15 minutes every time |
|
Objects |
① Range:0.1us/cm² —20us/cm |
|
② Datum:66/100MΩ |
|
|
③ Testing board range:A Pattern:600-4200cm² |
|
|
Dimensions |
Standard:1050*600*920mm Optional:1401*600*1000mm |
|
Weight |
Standard:about115Kg Optional:about150Kg |
