Customized 225L Temperature Humidity Chambers , Stainless Steel Plate Testing Equipment
Product Details:
| Place of Origin: | Guangdong, China (Mainland) |
| Brand Name: | HAIDA |
| Certification: | ISO 9001:2000; ISO 9001:2008; QS-9000; ISO 14001:2004; CE, SGS, SMC, CMC, CPA, CE,CMA,IMC |
| Model Number: | HD-E702-25 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Each set protected with resin fiber and PP film, then put into Strong wooden case with operation man |
| Delivery Time: | 20 days after order confirmed |
| Payment Terms: | L/C,D/A,D/P,T/T,Western Union,MoneyGram,In cash, escrow |
| Supply Ability: | 300 Sets per Month Haida |
|
Detail Information |
|||
| Display: | LCD | Humid. Range: | 20 ~ 98 Percent R.H. |
|---|---|---|---|
| Material: | Stainless Steel Plate(SUS304) | Product Name: | Thermal Cycling Device |
| System: | Balanced Temperature, Balanced Temperature & Humidity Control System | Temp. Range: | -70°C~150°C |
| Power: | 0.1°C, 1 Percent, P.I.D Control | Port: | LCD |
| High Light: | humidity temperature test chamber,humidity and temperature controlled chamber |
||
Product Description
Customized 225L Temperature Humidity Chambers , Stainless Steel Plate Testing Equipment
Specifications Of Temperature Humidity Chambers
1. Manufacturer,can be customized
2. In stock,fast delivery
3. Reasonable price
4. 1year warrenty
Programmable Constant Temperature Humidity Chambers
Programmable Constant Temperature Humidity Chambers can simulate different environment condition. It's appropriate for testing material performance, such as resist heat, resist dry,resist humidity and resist cold. That can define performance of material.
Design Standard: GB/T2423/5170/10586, JIS C60068, ASTM D4714, CNS3625/12565/12566
Characteristics:
1. Programmable Constant Temperature Humidity Chambers Use the high precision microcomputer touch temperature and humidity controller with high stability of platinum resistance to temperature and wind speed in the circulatory system of temperature and humidity test.
2. Programmable Constant Temperature Humidity Chambers control temperature&humidity well-distributed, precisely and steady.
3. Programmable Constant Temperature Humidity Chambers Completely independent system separate for testing in high temperature, low temperature and constant temperature&humidity environment.
2. Parameters
Inspect standard:JJF-1101,GB/T 10592,GB/T 10586
Testing standards:YD/T 2061,HB 7122.3,6783.7,GJB 5382.7,GJB 150,GB/T 2423,5170.2,5170.5,5179.2, ASTM E512,NF EN 60068-2-38,CNS 12565,12566,KS C0227,KS C022
3. Function and Features
1) The test machine is mainly used in testing the adaptability of electronics, electrical appliances, food, automobile, rubber and plastic, metal and other products, parts and materials in the high and low temperature alternating hot and humid environment when storage, transport and using；
2) It is an reliable test equipment for all kinds of electronic, electrical, electronics, plastics raw materials and devices to do testing such as cold, heat, moisture, resistance to dry and the quality control ；
3) Especially suitable for optical fiber, LCD, crystal, inductor, PCB, batteries, computers, mobile phones, rubber, plastics and other product.
4) The new perfect design, the appearance of high texture level, the system extracts Japan, West Germany, the essence of design and manufacture of advanced technology.
5) Balanced temperature humidity control system (BTHC), to PID mode control SSR, so that heated humidification system was equal to heat loss capacity, it could be used long-term stability;
6) All-capillary, automatic load capacity adjustment system technology, more expansion valve system more stable and reliable, precise temperature and humidity control, heating and cooling rate of rapid, steady, uniform, saving valuable time for users.
4. Technical parameter:
|
Model |
TT-E702-225 Thermal Cycling Device |
|
System |
Balanced Temperature & Humidity Control System |
|
Temp. range |
-70°C~150°C |
|
Humid. range |
20 ~ 98 percent R.H. |
|
Temp. & Humid. accuracy |
± 0.3°C; ± 2 percent R.H |
|
Temp. & Humid. regularity |
± 2°C; ± 5 percent RH |
|
Resolution |
0.1°C, 1 percent, P.I.D control |
|
Heating up |
-40°C ~ +100°C within 45 min |
|
Heating down |
20°C~ -20°C within 40min |
|
Interior dimension(W×D×H) |
50×75×60cm |
|
Exterior dimension(W×D×H) |
95x165x115cm |
|
Interior material |
Stainless steel plate(SUS304) |
|
Exterior material |
Stainless steel plate(SUS304) |
|
Insulation |
Rigid foam |
|
Refrigeration system |
Air cooled, Hermetic compressor, single stage refrigeration system. |
|
Display |
LCD |
|
Safety devices |
No fuse breaker refrigerator over load relay, Refrigeration High pressure Switch, Over Temp, Protector, Protection relay, Protection fuse, Water Lever protector, Overheat protector, Alarm |
|
Accessories |
Viewing window, Shelves (freely adjustable 2 pcs.), Cable port(Ø50mm)Chamber lamp. |
|
Weight |
Approx. 300 kg |
|
Power |
AC220V±10 percent 50/60Hz |
|
|
|
|
|
|
