Hole Inspection Machine For PCB Testing Equipment , PCB tester machine
Product Details:
| Place of Origin: | China |
| Brand Name: | ASIDA |
| Model Number: | JK3600 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1Set |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Wooden Carton |
| Delivery Time: | 2Weeks |
| Payment Terms: | T/T, L/C, D/A, D/P, Western Union, MoneyGram |
| Supply Ability: | Negotiation |
|
Detail Information |
|||
| Repeat Accuracy: | Repeat Accuracy | Model Number: | JK3200/JK3600 |
|---|---|---|---|
| Product Name: | Hole Inspection Machine | Inspection Speed: | 6.5、10、12.5m/min(Adjustable) |
| High Light: | pcb board testing equipment,circuit board testing equipment |
||
Product Description
Hole Inspection Machine For PCB Testing Equipment , PCB tester machine
Product Attributes:
|
Product name |
Hole Inspection Machine |
|
Brand Name |
ASIDA |
|
Model Number |
JK3200/3600 |
|
Place of Origin |
China |
|
Packaging Details |
Wooden Carton |
Usage
ASIDA-JK3600 Inspection Hole Machine is used to inspect completed PCBs for drill hole defects. The number and quality of drilled holes is checked and the board is assigned to be either OK or NG, the resulting PCBs are sorted accordingly.
Characteristics
-
User friendly interface, no special training required.
-
Long bar LED light source.
-
Detection speed can reach up to 12.5m/min.
-
30 degree angle detection range, inputed boards can be off centre by up to 30 degrees.
-
Capable of checking two boards simultaneously.
-
Network maintenance function, can link to other systems to display OK/NG information.
-
Personalised software designed to specific customer requirements.
Efficient
①JK3200 is equipped with double sorting equipment, which can detect two plates at the same time.
②JK3600 is equipped with six sorting equipment,which can detect six plates at the same time.
Hole Checker Client:
|
Accuracy |
①Repeat accuracy:±40µm |
|
②Measurement Accuracy:±40µm |
|
|
Inspection Speed |
6.5,10,12.5m/min(Adjustable) |
|
Objects |
① Aperture range:0.15～10mm |
|
②Size of measurable boards:100×150～630×650mm |
|
|
③ Thickness range of measurable boards:0.3～10mm |
|
|
④Hole margins:≥0.15mm |
|
|
Dimensions |
3550*1200*1100mm |
|
Weight |
400-450Kg |
