Li-polymer Square battery Online X-ray Inspection System with Real-time Monitoring
Product Details:
| Place of Origin: | China |
| Brand Name: | Asida |
| Model Number: | XG5100 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Wooden Carton |
| Supply Ability: | 120 sets per yeat |
|
Detail Information |
|||
| Application: | Lithium-ion Battery | Series: | X Ray Testing Machines |
|---|---|---|---|
| Testing Capacity: | 25 Pieces Per Minute | ||
| High Light: | x ray inspection equipment,battery testing machine |
||
Product Description
Li-polymer square battery Online X-ray Detection Machine
Brand : ASIDA
Model : XG5100
Applied products : Li-polymer square battery and finished battery
Online X-ray Detection Machine Usage:
The equipment is mainly applied to square battery industry with online or off-line model.
Characteristic
1. Automatic sorting
Automatic detection and sorting OK/NG products.
2. Real-time monitoring,
Real-time monitoring the state of all actions, signal, hardware,and show on the software interface.
3. Images and data real-time online displaying.
Test data and images of many parts of the same battery is shown in the same software interface,
which is convenient observation recognition.
4. Safety protection
The whole equipment safety interlock, triple protection function, any part of the fuselage surface
radiation meet safety standards.
Technical parameters
|
X-ray Tube |
Tube Voltage |
MAX 110KV |
|
Tube Current |
MAX 450uA |
|
|
Focal Spot Size |
5μm |
|
|
Cooling Mode |
Strong wind cooling |
|
|
Linear array detector |
Sensitive area |
235mm×13mm |
|
Efficiency |
Detection Efficiency |
≥25ppm |
|
False Rate |
≤2% |
|
|
Missing Rate |
0.0% |
|
|
Excellent Products Rate |
≥99.5% |
|
|
Safety Standard |
International Radiation Safety Standards |
≤1usv/hr |
