PP Cutting Machine 60 m / min Speed , Prepreg Automatic Cutting Machine
Product Details:
| Place of Origin: | China |
| Brand Name: | Asida |
| Certification: | 1000 |
| Model Number: | CQ |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1set |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Wooden Carton |
| Delivery Time: | 2WEEKS |
| Payment Terms: | T/T, D/P, L/C |
| Supply Ability: | Negotiation |
|
Detail Information |
|||
| Cutting Length: | 50mm~750mm | Speed: | ≤ 60 M/min |
|---|---|---|---|
| Average Power: | ≤ 9 KW | Cutting Thickness: | 0.04 Mm~0.3 Mm |
| Cutting Width: | 200 Mm~1270 Mm | Cutting Length: | 50 Mm~750 Mm |
| High Light: | prepreg cutting machine,pp cutter |
||
Product Description
PP Cutting Machine 60 m / min Speed , Prepreg Automatic Cutting Machine
Usage
This product is used for cutting various types of prepreg, the cutting edge is neatly out of the material, no flash, can not afford to dust, not white, not charred, and edged automatically, no follow-up treatment, has solved the problem of plagued the industry for years of traditional mechanical cutting pregneg dust pollution, which caused by films, glass falling etc.
Feature
The machine is fully automatic equipment, with start/pause/three emergency stop buttons on the operating panel, through the relevant technology, the prepreg at the cutting edge was cut in a very short period of time to soften but not the case for cutting cured; Neat smooth edge, no dust, glass falling.
The machine adopts the advanced servo control system, high precision cutting, high speed machine can solve the case long made up the problem of poor measurement
3PLC control, and packaging of all process parameters, the process of using the touch screen you can set up different types of PP, the system will automatically bring up the marching parameters; The operator set the size of the cut, cutting number and speed of cutting, the machine cutting automatically, simply operation, the saving cost of human resources, a increase of productivity, while ensuring the health of employees.
Parameters
|
ITEM |
SPECIFICATION |
| Cutting Length | 50 mm~750 mm |
| Cutting Width | 200 mm~1270 mm |
| Cutting Thickness | 0.04 mm~0.3 mm |
| Cutting Accuracy | ± 1.0 mm |
| Cutting Effect | Smooth edges and no dust |
| Speed | ≤ 60 m/min |
| Dimensions | 2600mm*2300mm*1700mm(L× W× H) |
| Weight | About 1500 kg |
| Average Power | ≤ 9 kW |
Maximum roll diameter |
≤ 320mm |
| Equipment Installation Requirements |
|
| space | 3500 mm*3500 mm*2000 mm(L*W*H); |
| Temperature | 20± 2 ° |
| Relative Humidity | 50%± 5% RH |
| Power |
Three phase and five-wire systerm, Voltage AC380, Frequency 50 Hz , Current≥ 40 A; |
| . Air power | 0.7 MPa~1.0 MPa. |
